Uni Directional Knife Edge Gate Valve

Get a Price/Quote

MOQ : 1 Piece

Uni Directional Knife Edge Gate Valve Specification

Application
Mining, Paper & Pulp Industries, Chemical Plants, Waste Water Treatment

Temperature of Media
-20C to +180C

Connection
Wafer, Lugged, Flanged

Structure
Uni-directional Knife Edge Gate

Material
Body: Cast Iron, SS304, SS316; Gate: SS304, SS316; Seat: EPDM, PTFE, Metal

Surface Treatment
High Performance Epoxy Coating, Mirror Finished Gate

Pressure
Up to 10 Bar

Dimension (L*W*H)
Dependent on Nominal Bore and Pressure Class

Power
Manual, Pneumatic or Electric Actuation

Media
Water, Slurry, Pulp, Powder, Granules

Port Size
50 mm to 1200 mm (2 to 48)

Weight
Varies With Size and Material (Typically 10 kg to 350 kg)

End Connection Drilling
To ANSI B16.5 / DIN / IS Standards

Body Test Pressure
1.5 times rated pressure

Size Range
2" to 48" (DN 50 - DN 1200)

Packing
High Quality PTFE or Graphite Packing with Gland Arrangement

Standards
Conforms to MSS-SP-81, IS, ASME, DIN

Bonnet
Rising or Non-Rising Stem, Optional Bonneted/Bonnetless Design

Maintenance
Low Maintenance, Replaceable Seat and Seals

Sealing Type
Soft Seated or Metal Seated

Design Feature
Knife Edge Gate for Cutting Thick Media

Flow Direction
Uni-directional, Sealing on One Side

Color
Blue or as per Customer Requirement

Face to Face Dimension
According to MSS-SP-81 Standard

Operation
Handwheel, Lever, Pneumatic Cylinder, Electric Actuator

Seat Test Pressure
1.1 times rated pressure

Uni Directional Knife Edge Gate Valve Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Week

Delivery Time
2-5 Days

Main Domestic Market
All India

About Uni Directional Knife Edge Gate Valve

Jump on brilliant performance and instant checkout convenience with our Uni Directional Knife Edge Gate Valve-decorated for excellence in every flow. Find ravishing versatility with operation modes including handwheel, lever, pneumatic cylinder, and electric actuator. Soft or metal seated, the valve offers both bonneted and bonnetless designs, conforming to global MSS-SP-81, IS, ASME, and DIN standards. Its knife edge gate swiftly cuts through thick media, ensuring sealing on one side, low maintenance, and easily replaceable seat and seals. Available in sizes from 2" to 48", this valve features a robust blue epoxy-coated body, mirror-finished gate, and is suited for water, slurry, pulp, powder, or granules across diverse industries. Stock ready for shipment from India to global destinations!

Versatile Usage and Exceptional Material Features

The Uni Directional Knife Edge Gate Valve is engineered for heavy-duty applications in industries like mining, chemical processing, paper and pulp, and waste water treatment. Its robust build from cast iron or stainless steel, along with EPDM, PTFE, or metal seating options, makes it ideal for handling water, slurry, pulp, powders, and granules under harsh conditions. Choose this valve for low maintenance operation, superior media sealing, and reliable knife-edge cutting for thick or viscous materials.

Export Markets, Certifications, and Sample Availability

Our ravishing range of Knife Edge Gate Valves is offered for export to key markets in Asia, Europe, the Middle East, and Africa. Stock ready for quick dispatch, these valves can be shipped globally with proper certifications including MSS-SP-81, IS, ASME, and DIN. We offer free samples to qualifying buyers to demonstrate valve performance before purchase. Trust our certified quality and prompt shipping for seamless transactions every time.

FAQ's of Uni Directional Knife Edge Gate Valve:

Q: How does the Uni Directional Knife Edge Gate Valve ensure efficient media cutting?

A: The valve is designed with a specialized knife edge gate that cuts through thick or viscous media, making it highly efficient for challenging industrial applications such as slurry or pulp management.

Q: What operation modes are available for this gate valve?

A: You can choose from handwheel, lever, pneumatic cylinder, or electric actuator, depending on your automation and operational needs.

Q: Where can this valve be applied most effectively?

A: The valve is ideal for industries such as mining, paper and pulp, chemical plants, and waste water treatment due to its robust construction and effective media handling.

Q: What materials are used in the construction of this valve?

A: The body is crafted from cast iron, SS304, or SS316, with gate and seat options including EPDM, PTFE, or metal, all topped with a high-performance epoxy coating and a mirror-finished gate.

Q: What certifications do these valves carry?

A: Our valves conform to major standards including MSS-SP-81, IS, ASME, and DIN, ensuring compliance with international quality and safety specifications.
